PCB Automatic Stencil Printer Machine Smt Line In Led Light Production Line

Features of SMT Stencil Printer

1. PCB transport and clamping system

①　The PCB loading direction can be selected and combined freely.

②　Unique crafted internal gear conveyor belt to prevent jamming.

③　Programmable transport speed control makes PCB stop more precise.

④　Adopt flexible side clamps and segmented supports to effectively clamp the PCB to ensure a fully balanced contact between the PCB and the steel mesh.

⑤　The optimally designed module drive structure effectively improves the stability of the platform calibration, and realizes ultra-small transmission under fine-tuning, so that the machine can meet the printing requirement of higher precision. The structure is simple and reliable, the adjustable is convenient, and the height adjustment of the support PIN of the PCB board with different thicknesses can be quickly realized.

• Stencil positioning system

①　Arch bridge-shaped suspension hanging direct-connect scraper.

②　The size of steel mesh is universal, with good and wide applicability.

③　Segmented fixed steel mesh frame.

• Scraper system

①　Cast aluminum scraper beam to ensure smoother running of scraper.

②　Programmable suspension self-adjusting stepper motor drivers print head.

③　Bilateral double-slider positioning type slide rail structure ensures the accuracy and smoothness of running before and after printing.

④　According to the different pressure requirements of the front and rear squeegees and the stability of the lifting and lowering, to prevent the leakage of solder paste, the blade has a certain elastic clamping design, the pressure of the squeegee, the lifting speed, the printing speed, and the printing range are all software-adjustable. Provide a variety of demouding methods to meet different requirement of PCB, provide customers with a good printing control platform.

⑤　Slide rail type scraper system, improve operation stability and prolong lifetime.

⑥　The fully closed-loop scraper pressure feedback device monitors the scarper pressure at all times, making the printing more full.

⑦　Embedded scale,never fall off.

• Operation interface

①　Easy-to-learn and easy-to-use friendly operation interface

②　With good Human-machine dialogue function

③　Make program files with teaching and navigation functions,with prompts for each step.

④　One-key switch between Chinese and English, with operation log, fault record analysis and diagnosis and other functions.

• Image and optical system

①　X,Y axis adopts high-precision grinding ball screw,driven by servo motors at both side.

②　The polarizer is added inside, and the Mark of different shapes is automatically and accurately grasped, and the upper, lower and coaxial three-way uniform light sources.

Paremeter of Stencil Printer

SMT Production Line Solution:DOB Bulbs/panel light/Downlight/Floodlight/striplight/tube light,etc

RFQ

Q : Is there any quality guarantee?

We stick to quality first, client-oriented, Continuous improvement!

Q: What is SMT Machine?

This is an LED lamp patch machine using surface mount technology.

Q: Whether the machine's after-sale service is guaranteed?

Each of our machines has a one-year warranty and will regularly visit customers for use.

Q: What we can do for you?

A: We provide SMT machine,we can aslo provide Production line scheme and so on.Professional Technical Support and Service.

Q: What is your delivery date?

A: The delivery date is about 25-30 days after receipt of deposit.

Q: What is your payment terms?

A: 30% deposit and 70% balance before shipment.

Q:This machine is easy to use ? if I have no experience, I can also operate it well ?

A:Yes, our machine is designed to use easily, Normally it will take you 1 day to learn how to operate, if you are a technician, it will much faster to learn.
