Technical Paremeter
| PCB Size | 500*450mm |
| heads | 10PCS |
| Feeder station | 52PCS |
| Components | 0201~15MM packaging material and IC material(Optional fixed camera
for 0201~35*35MM), Other component size can be customized |
| X,Y,Z Axis Drive way | High-end magnetic linear motor |
| Mounting Speed | 48000 CPH(Under best condition) |
Application
Method of maintaining SMT Mounter electromagnetic valve
1. During manual operation, first confirm the safety.
2.Regularly discharge the condensed water accumulated in the air
filter.
3.Reduce the use of electromagnetic valves. Check the operation of
electromagnetic valves switch once a month to avoid failure.
4.When disassembling the mounter, please have the necessary
equipment to prevent the driven object from falling and unable to
operate normally. After this process, please cut off the air source
and power supply and pay attention to the residual air pressure.
5.The maintenance process of the mounter shall be carried out in
the order of the
operation as far as possible.
Introduction to our company
• Today, ETON Automation has successfully developed LED patch
equipment that can quickly improve assembly production efficiency
and reduce labor costs, and a complete after-sales service system
has won the recognition of the market and the majority of
customers, and has stabilized its leading position in the patch
industry.
Our Services
Exhibition
ETON committed to creating an international pick and place machine
brand. We have participated in many exhibitions every year.
Including domestic exhibitions and foreign exhibitions(except the
epidemic period).Not only in China, India Delhi, Indian Mumbai,
Pakistan Karachi, Turkey Istanbul etc.
Packaging
Step 1: Wrap the machine with film first
Step 2: Pack with foam cotton
Step 3: Vacuum bag packaging and vacuuming
Step 4: The film is then wrapped around and fixed
Step 5: Fix the four feet with foot cups to prevent them from
slipping during transportation
Step 6: Start packing in wooden boxes, one machine and one wooden
box.
FAQ
Q:How long is the time of delivery?
Generally, the test delivery period is one month.
Q:If my order is very urgent, how long you can proceed?
We have helped many clients with their urgent demand. If your order
is urgent, please check with our specialists to see if we can help.
Q:How are the products packed for sea shipment?
Most of the products have their unique packing, Then we put them
into a carton. The cartons are sealed with tape.
Q:How can you make sure that the products won't be damaged or wet?
We take multiple measures to protect the products. They are first
packing with individual. We put them into a carton and wrapped with
plastic film and sealed with tape to keep the cartons in position
and protect them from water.
Related SMT machine
We can provide you a whole SMT line solution and equipment, you can
look this picture, we have semi-auto/full-automatic stencil
printer, glue dispenser(this machine is mainly for making led
lens), conveyor, reflow oven, etc.
We can meet your any demands for equipment, and pursue quality
higher than price for machine manufacturing.
