PLC PCB Conveyor Sturdy Transplanting Machine For Moving PCB Boards

High-quality sturdy transplanting machine for moving PCB boards

Structure

The basic components are mainly composed of rack components, transfer trolleys, conveying guide rails, and electrical controls. It can be used with industrial electronic products such as cylinder stroke switch and solenoid valve.

Features:

It is suitable for SMT production line to realize parallel load transfer between two positions for confluence or diversion.

1. The frame is made of thickened sheet metal.
2. Guide rail is made of special aluminum.
3. The shifting action is driven by a stepper motor.
4. The track is driven by a stepper motor.
5. Panasonic PLC programmable controller control.
6. Touch screen operation (display control).
7. Single/double shift trolley is optional.
8. Single/double track operation structure is available.
9. Compatible with SMEMA interface.
10. Smooth design buffer deceleration.
11. A variety of length shifts are available.

Technical parameter

Application

It is an auxiliary equipment in an industrial automation production line, mainly used for the pick-up and drop-off of PCB boards.

Certificate

Our company has obtained a number of patented technologies since its establishment, such as: 9 invention patents, 12 software copyright patents, 112 utility patents, and so on.

Partner

Our products are sold to more than 20 countries and regions including South Korea, India, Vietnam, Tunisia, Egypt, and Turkey.

FAQ

Q: What can we do for you?

Answer: We provide SMT high-speed placement machines, and can also provide production line solutions. Professional technical support and service.

Q: What are your payment terms?

Answer: TT pays 30% in advance, and pays off the remaining 70% before shipment.

Q: Is this machine easy to use? If I have no experience, can I operate it well?

Answer: Yes, our machine is designed to be easy to use. It usually takes you 2-3 days to learn how to operate. If you are a technician, it will be much faster to learn.
