Mitsubishi PLC Pcb Loader Unloader Machine Automatic PCB Conveyor

High quality and good performance un-loader machine PCB conveyor automatic

The description of un-loader machine

It is mainly used at the end of the SMT production line to store the soldered PCB boards through the material rack. Its frame is driven by a special aluminum profile guide rail and a special thousand bird type plastic chain, driven by a 90W Taiwan brake motor, and the magazine moves up and down through a ball screw. It uses a pneumatic clamp structure and is controlled by a Mitsubishi PLC.

Technical parameter of un-loader machine

Feature of receiving machine

1. Mainly used at the end of the SMT production line, to store the soldered PCB board through the material frame, with automatic board receiving function;
2. Reduce the pad oxidation caused by manual boarding, and greatly reduce human resources
3. The control system adopts PLC control, and the operation interface adopts touch screen, with stable performance and convenient operation;
4. The frame structure adopts sheet metal welding, aluminum profile construction, and the surface is painted;
5. The lifting structure adopts the motor lifting setting, and the effective setting step can be selected as; 10mm, 20mm, 30mm, 40mm.

Uses

can be used for the transmission of circuit boards in the LED lighting industry.
