Brand Name : | ETON |
Model Number : | E8D-1200 |
Certification : | CCC/CE/SIRA |
Supply Ability : | 50 pcs per month |
Price : | FOB USD 26000~86000/sets |
Payment Terms : | L/C, T/T |
Delivery Time : | 15~30 days |
Introducing brand
Company quality principle
Multifunctional pick and place machine E8D-1200
✹The machine HT-E8D-1200 with double module,total 24 head,each part 12 heads,can produce two types of product at the same time.
✹The X axis is magnetic linear motor,Y axis and Z axis is servo motor,very good performance and high accuracy.
✹It’s intelligent,can product different types of LED light and electric board,such as tube,bulb,strip,panel,downlight,streetlight,power light
✹Its high precision,apply to LED chips,resistor,capacitor,IC,shaped component etc.
✹It is highspeed machine,the optimum speed is 90000 CPH.
Technical parameter
Dimension | 2550*1650*1550mm |
weight | 1700kg |
PCB size | Max: 1200*300mm Min: 100*100mm |
No.of camera | 24 sets of imported camera |
Mounting height | <15mm |
Component | LED,capacitor,resistor,shaped component,etc. |
Power consumption | 8 KW |
Optimum speed | 90000CPH |
Feeder station | 48 PCS |
Nozzles | 24 PCS |
X Y Z axis drive way | High-end magnetic linear motor and servo motor |
Mounting mode | Group picking and separate placing,separat picking and separate placing |
Mounting Space | 0.2mm |
Mounting Precision | ±0.04mm |
Feeding way | Electric feeder with double motor |
Operate system
Machine is very intelligent and easy to operate,like the intelligent phone,also the software is made by our company,more intelligent and operate.
System | Windows 7 |
Software | R&D independently |
Display | Touch screen monitor |
Input device | Keyboard, Mouse |
Machine application
The machine E8D-1200 can product different types of LED light and electric board,such as tube,bulb,strip,panel,downlight,streetlight,power light.
About our industrial park
SMT line
In the SMT line, a SMT production line is composed of different machines
