SMT professional manufacturer pick and place machine with high precision LED making machine

Advantages of RT series design

• Suitable for mounting high components. Because during the high-component mounting process, if the PCB is moving, the mounted components are prone to displacement.
• Products suitable for mounting small boards, because the PCB board is fixed after entering the board, if it is clamped again, it will vibrate other mounted components.

Machine information

• The machine is single module linear motor multifunctional pick and place machine,total 10 head.
• Its high precision,apply to LED chip,resistor,capacitor,IC,shaped components etc.
• The mounting speed of RT-1 is 30000 CPH.

Feeding system

Application & components

• Components:LED,capacitor,resistors,shaped components,etc.
• Application:bulbs, panel lights, drivers, downlights, DOB,streetlight electric board and so on.

Actual capacity

1. The optimal capacity of RT-1 is 30000-35000 CPH.
2. Factors that affect the actual production capacity: the time of entering and exiting the board, the size of the board, the number of heads used, the type of components, the number of components, etc.

Precautions for using the machine

1. Before using the Pick and Place machine, you must understand the basic parameters of the placement machine;

2. Before running the Pick and Place machine, the operator should do a comprehensive inspection of the machine.

3. According to the boot operation sequence to implement the Pick and Place machine, there must have a detailed machine operation instructions;

4. It is necessary to conduct regular troubleshooting and maintenance work on the Pick and Place machine in a timely manner.

Introducing company

Our company set up 2011.High efficiency High quality and High Stable are the technology of ETON,strong technology innovation and strict pursuit of quality control,with excellent service,ETON has created superior value for customers as the outstanding worldwide brand of highspeed SMT machine with good reputation.

Industrial Park

Our company’s industrial park was successfully completed,equipped with an advanced processing and manufacturing center,strict quality control,and standardize production,streamline production production,and has invented the fastest automatic pick and place machine with speed 250000 CPH,which save much labors and space of production.

Payment and Delivery date

1. Term of Payment:30% depositing on the date of signing contract,70% payment before delivery.

2. Delivery date:Within 30 days after receiving the deposit

Shenzhen ETON Automation Equipment Co.,LTD. was establised in 2007,possess more than 300 staff at present and cover an area of more than 20000 square meters,is the largest leading manufacturer of high-speed pick and place machine and SMT machine for LED light production and Electronic field,which is also a high-tech enterprise and top brand well-known in China with good reputation.


  ETON invented the fastest automatic pick and place machine with speed 150000CPH,which is the fastest machine in the world,awarded many global first technology patent,also invented the global first machine for any length of 1M 5M 50M 100M 500M flexible LED strip,won large market in USA,KOREA,INDIA,GERMANY,EGYPT,TURKEY,VIETNAM,TUNISIA ETC.


  Since the establishment of the company, with the green and energy-saving development trends of global illumination and rapid development of LED industry and its requests for the manufacturing craft, ETON has seized the opportunity and risen quickly, they have independently researched、designed、manufactured a set of quicker、more stable、more optimal LED fully automatic, high speed, energy-saving chip mounter and multi-function chip mounter, which have been highly recognized in the industry for its absolute advantage in speed, stability and capacity, at the same time, it have solved the offset and fling material issues when producing 1.2 meters, 1.5 meters lamp plates and wireless long FPCB and shaped component at a high speed. ETON has passed ISO9001 quality management system certification and has obtained more than one hundred of patents and certificates, including for utility model, personal invention, software copyright and so on. We have established cooperative relationship with well-known enterprises at home and abroad, such asMLS,OPPLE,NVC,Navigation,PAK,ETI,FSL, Home Lighting,Yangguang Lighting, XSY, Sansi, India RK, India SURYA, Vietnam RANGDONG, Egypt FUTEK etc..

  Our products have been exported to more than 20 countries and regions, including Korea, India, Vietnam, Tunisia, Egypt, Turkey and so on. Meanwhile, the company has created customer service center, where records every customer and the sale of every set of machine permanently. Its existence can timely solve customer’s questions when using it, which truly provides the convenience and assurance for our customers.

  “High efficiency” “High quality” and “Stability” are the core technology of ETON,technology innovation and strict quality control,with excellent service,ETON has grown into the outstanding worldwide brand of SMT machine with good reputation.
