    Automatic Calibration SMT Mounting Machine 250000CPH For Strip

    Ask Lasest Price
    Brand Name : ETON
    Model Number : HT-T9
    Certification : CCC,CE,SIRA
    Payment Terms : T/T
    Supply Ability : 50 sets per month
    Delivery Time : 30 days after deposit
    • Product Details
    • Company Profile

    Automatic Calibration SMT Mounting Machine 250000CPH For Strip

    Automatically calibration ultra-high speed SMT machine for flexible strip( no wire)

    Product description

    Dual arm four module high speed pick and place machine, capacity reach 250000CPH
    Vision alignment, Mark correction
    Components: LED 3014/3020/3528/5050 and capacitors, resistors, bridge rectifiers, etc
    Application: flexible strip( any length)

    Features

    High speed

    Dual arm four module, 17 nozzles for each mounting part, part A or part B can be mounted separately or synchronously.
    The capacity reach 250000CPH
    Producing 4 types materials at the same time with high capacity, available for 5 M,50 M or any length of flexible strip and roll to roll.

    High precisionWith a new visual recognition system, five imported cameras, visual alignment, Mark correction technology, it can be automatically corrected, available for RGB
    Exclusive patent technologygroup to take and group to mount


    Technical parameter

    HT-T9 pick and place machine
    DimensionLength* Width* Height3100mm*2300mm *1550mm
    Total weight1700kg
    PCBPCB Size250mm*any length
    PCB Thickness0.5-1.5mm
    PCB ClampingVacuum adsorption, cylinder splint, adjustable track width
    Mounting modeGroup to take and group to mount
    O.S.SystemWindows 7
    SoftwareR&D independently
    DisplayTouch screen monitor
    Vision SystemNo. of camera5PCS(Digital camera)
    Vision alignment, Mark correction
    Mounting precision+0.02mm( repeat precision)
    Mounting speed200000-250000CPH
    ComponentsLED3014/3020/3528/5050, capacitors, resistor, bridge rectifiers, etc
    No. of feeders station68PCS
    No. of nozzles68PCS
    XYZ Axis drive wayHigh-end magnetic linear motor + servo motor
    Feeding wayElectric feeder with double motor





    Company information

    Shenzhen ETON Automation Equipment Co. LTD, which is advanced technology and innovation drives the revolution of market rapidly, and obtains a number of intellectual property technologies, including 9 invention patents,12 software copyrights, moreover, ETON has invented the fastest automatic pick and place machine with speed 170000CPH, which save much labors and space of production, got large market share in USA,KOREA,INDIA,GERMANY,EYPT,TURKEY,VIENAM,TUNISIA,THAILAND more than 20 countries.



    Certificate





    Packaging and payment

    vacuum wooden boxes packing
    Terms of payment: 30% depositing on the date of signing contract,70% payment before delivery


    After sales service

    Warranty period: one year

    Provide latest information about technology and equipment

    Free software upgrade


    FAQ

    Q:What is the delivery date?
    We will deliver the goods after 30 days' deposit.
    Q:Is electrical control developed independently?
    Yes, the electrical control is by ourselves and have exclusive patent technology.
    Q:Are you a manufacturer or trading company?
    manufacturer. We have our own industrial park.
