PCB pick and place machine high precision LED flexible making machine with good stable

Shenzhen Eton Automation Equipment Co., Ltd.
Contact Now
    Buy cheap PCB pick and place machine high precision LED flexible making machine with good stable from wholesalers

    Buy cheap PCB pick and place machine high precision LED flexible making machine with good stable from wholesalers
    • Buy cheap PCB pick and place machine high precision LED flexible making machine with good stable from wholesalers

    PCB pick and place machine high precision LED flexible making machine with good stable

    Ask Lasest Price
    Brand Name : ETON
    Model Number : HT-F7S
    Certification : CCC/CE/SIRA
    Supply Ability : 50 sets/month
    • Product Details
    • Company Profile

    PCB pick and place machine high precision LED flexible making machine with good stable

    PCB pick and place machine high precision LED flexible making machine with good stable


    Product Parameter


    Dimension2700*2450*1530mm
    Total weight1400kg
    PCBsize

    Max:1200*330mm

    Min:50*50mm

    Thickness0.1-6mm
    ClampingMounting clamping
    Mounting modeGroup picking and separate placing,separate picking and separate placing.
    O.S.SystemWindows 7
    SoftwareR&D independently
    DisplayTouch screen monitor
    Input deviceKeyboard,mouse
    Vision systemcamera5 PCS digital camera
    Mounting precision0.02mm
    Mounting element height≤5mm
    Mounting speed150000-170000 CPH
    ComponentsLED3014/3020/3528/5050 and capacitor,resistors,bridge rectifiers,etc.
    Components space0.2mm
    Feeder station68 PCS
    Nozzles34 PCS

    Product features


    1. The machine Mainly for half meter and 1 meter flexible light,Tubes and panel lights can also be mounted.

    2. The mounting head is respectively in the left and right groups, each group has 17 nozzles.

    3. Calibration automatically,high precision,available for RGB.

    4. Exclusive patent technology:Group to pick and group to mount


    Mounting product

    • The machine HT-F7S is highspeed pick and place machine,speed reach 170000CPH
    • Apply to the 0.6M,0.9M,1.2M rigid PCB and 0.5M,1M LED flexible strip.


    Introducing brand


    ETON is committed to the development and production of LED high-speed SMT machine, multifunctional SMT machine, automatic SMT machine, and has obtained a number of national patent certificates.




    Our Industry Park


    The factory belonging to our company has been successfully built, equipped with advanced processing and manufacturing centers, scientific research buildings, exhibition halls, etc., to ensure quality from the source and further standardize production processes



    Package and delivery

    ❆Standard export vacuum waterproof package

    ❆Strong wooden package for ensure safely delivery of heavy and large equipment

    ❆Delivery:By air,sea and railway.


    Payment and service


    Our company Products


    Our company produces high-speed machines, multi-function machines and SMT machines



    FAQ

    Q:Is it safe during the delivery?

    A:All the machine is packed safely,by standard strong wooden carton with vacuum package.


    Q:What is your transportation?

    A:Sea transportation,land carriage and air transportation is OK.


    Q:4.How is your training?

    A:We will send our engineer to your factory to install machine and training freely.If client is India,we have service office in India,can support quickly.


    Q:If I have no experience,The machine is easy to use?

    A:Yes,our machine is designed to use easily,usually 3 to 5 days to learn how to operate.
