    HT-XF: The minimum distance is 14 mm between two adjacent nozzle For SMD Mounting Machine

    Ask Lasest Price
    Brand Name : ETON
    Model Number : HT-XF
    Certification : CE CCC ISO
    Price : US $75,000-76,000 / Units
    Payment Terms : T/T
    Supply Ability : 50
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    HT-XF: The minimum distance is 14 mm between two adjacent nozzle For SMD Mounting Machine

    1. Product Description



    Apply to the SMT machine, PCB, LED hard light board and LED soft lamp strip etc.

    Apply to mounting LED 3014/3020/3528/5050/5730 etc.

    Apply to tube, bulb, strip, lamp, panel, ceiling light, down light, diaplay etc.

    Mounter speed: 150000~170000CPH

    Technical Parameter

    smt pick and place machine/led making machine

    DimensionLength2700MM
    Width1900MM
    Height1400MM
    Total Weight1300kg
    PCBPCB length widthMax:300*1200mm Min:300*60mm
    PCB thickness0.5~5mm
    PCB ClampingAdjustable pressure pneumatic.
    O.S.systemWindows7
    softwareR&D independently
    DisplayLED Monitor
    Input DeviceKeyboard, Mouse
    Feeding systemNo. of feeders34PCS
    No. of nozzles34PCS
    Feeder typeElectronic feeder
    Vision SystemNo. of Camera5 sets of imported camera
    Vision for the flight identification + MARK correction
    Mounting Precision±0.02mm chip
    Mounting Height<15mm
    Mounting Speed150000-170000 CPH(optimum)
    ComponentsLED 3014/3020/3528/5050/5730 etc.
    Components Space0.2mm
    Power220AC 50HZ
    Power Consumption5kw
    Operating Environment23℃±3
    Conveyor TransmissionMax Length:1200mm
    Transmission Speed>500mm/s
    Transmission DirectionSingle(left→right or right→left)
    Transmission ModeOnline drive
    Air pressure>5.0kg/cm2
    Electrical controlIndependent research and development by ETON
    Motion control card module 2 setsIndependent research and development by ETON
    X,Y Axies DrivingServo motor

    2. Company Information


    Company profile

    Shenzhen Eton Automation Equipment Co.,Ltd is a national high-tech enterprise which specializes in automatic high-speed SMT pick and place machines for customers, combining R&D, production, sales and service as one

    Company five level management policies: sincere business, focus on R&D, manufacturing intentions, considerate service, customer trust.

    • Eton Purpose: To create value for customers, creating benefits for society.
    • Eton Mission: Professional, Excellent technology, Share the results.
    • Eton goal: To create a national brand, build world-wide top brand Chinese enterprise.
    • Eton purpose: To create value for customers, creating benefits for society

    Our advantages

    Date Analysis Compared with other Manufacturers

    Manufacturers/ParameterOther company's F130Other company's 5M168Our Eton's HT-E8 mounterData Comparison
    Speed15000CHP18000CHP

    80000CPH


    4 to 6 times higher than others
    Nozzle4PCS6PCS18PCS3 to 5 times higher than others
    Precision0.03mm0.03mm0.02mmMore Precise
    Patent--------------Technology PatentsGlobal First
    Cost Performance20%30%100%3 to 5 times higher than others
    ScrewUnknown brandUnknown brandFujiJapanese famous brand
    motorUnknown brandUnknown brandKurodaJapanese famous brand
    cameraUnknown brandUnknown brandIDSGerman famous brand

    Our Service

    paste-pic-dp_uuid_ibstt

    1.Pre-Sales Service

    • 24 show online, ready to answer for you
    • Professional and detailed technical solutions
    • View our factory.

    2.Sales Service

    • Warranty: one year, offer the extended warranty service.
    • Training how to install the machine, training how to operate the machine..

    3.After-Sales Service

    • Engineers available to service machinery overseas.
    • Visit customers regularly and gather information
    • Provide latest information about technology and equipment
    • Our company has the office in Delhi, can provide convenient and fast service

    Delivery information

    • Machine is completed, ready for work and mature; each machine is 100% tested well, QC passed
    • Delivery time: 15 days after payment
    • Package: Standard export package(It also can be adjusted according to customer's requirement)

    paste-pic-dp_uuid_z6dseour service

    Why choose us

    our service 1.jpeg

    • We have our own top R & D team
    • Leaders of smt pick and place machine industry, “National high-tech enterprise” certification.
    • Each machine is 100% tested well, QC passed.( Many parts are imported)
    • Product has a good reputation in the market
    • Perfect service system
    • Stand on customer's point of view to help customers, look forward to establishing business relations

    If you are interested in our machine,kindly contact us.we look forward to doing business with you!
