8 Heads Multi-functional Pick and Place Machine HT-E8S LED Chip Mounter

Machines Window

In order to meet the rapid development of the lighting industry market demand, research and

development a multi-functional placement machine HT-E8S. HT-E8S is a new model pick and place

machine of Eton company. This machine designed for many kinds of PCB boards. Using newest high

magnetic linear motor, so the speed and accuracy is better than normal multi-functional machines.

HT-E8S Features

w High Accuracy Magnetic Linear Motor + Panasonic Servo Motor

w 8 heads 30 feeder stations

w Minimum mounting components 0402

w The Height of Head can be Set Automatically, Maximum Height 36MM

w Auto-optimization after coordinate generated

w Vision for the Flight Identification, Mark Correction

w Capacity can Reach 40000 CPH

HT-E8S Application

HT-E8S can meet 0402 components, Max mounting height can be 36MM. It’s suitable for various types

of drives, power supplies, circuit boards, lenses, linear bulbs, home appliance control panels, LEDs etc.

HT-E8S Main parameters

Shenzhen ETON Automation Equipment Co.,LTD. was establised in 2007,possess more than 300 staff at present and cover an area of more than 20000 square meters,is the largest leading manufacturer of high-speed pick and place machine and SMT machine for LED light production and Electronic field,which is also a high-tech enterprise and top brand well-known in China with good reputation.


  ETON invented the fastest automatic pick and place machine with speed 150000CPH,which is the fastest machine in the world,awarded many global first technology patent,also invented the global first machine for any length of 1M 5M 50M 100M 500M flexible LED strip,won large market in USA,KOREA,INDIA,GERMANY,EGYPT,TURKEY,VIETNAM,TUNISIA ETC.


  Since the establishment of the company, with the green and energy-saving development trends of global illumination and rapid development of LED industry and its requests for the manufacturing craft, ETON has seized the opportunity and risen quickly, they have independently researched、designed、manufactured a set of quicker、more stable、more optimal LED fully automatic, high speed, energy-saving chip mounter and multi-function chip mounter, which have been highly recognized in the industry for its absolute advantage in speed, stability and capacity, at the same time, it have solved the offset and fling material issues when producing 1.2 meters, 1.5 meters lamp plates and wireless long FPCB and shaped component at a high speed. ETON has passed ISO9001 quality management system certification and has obtained more than one hundred of patents and certificates, including for utility model, personal invention, software copyright and so on. We have established cooperative relationship with well-known enterprises at home and abroad, such asMLS,OPPLE,NVC,Navigation,PAK,ETI,FSL, Home Lighting,Yangguang Lighting, XSY, Sansi, India RK, India SURYA, Vietnam RANGDONG, Egypt FUTEK etc..

  Our products have been exported to more than 20 countries and regions, including Korea, India, Vietnam, Tunisia, Egypt, Turkey and so on. Meanwhile, the company has created customer service center, where records every customer and the sale of every set of machine permanently. Its existence can timely solve customer’s questions when using it, which truly provides the convenience and assurance for our customers.

  “High efficiency” “High quality” and “Stability” are the core technology of ETON,technology innovation and strict quality control,with excellent service,ETON has grown into the outstanding worldwide brand of SMT machine with good reputation.
