High Accuracy Smt Pick Place Machine Led Bulb Assembly Ic Smd Making Machine

    Buy cheap High Accuracy Smt Pick Place Machine Led Bulb Assembly Ic Smd Making Machine from wholesalers

    Buy cheap High Accuracy Smt Pick Place Machine Led Bulb Assembly Ic Smd Making Machine from wholesalers
    • Buy cheap High Accuracy Smt Pick Place Machine Led Bulb Assembly Ic Smd Making Machine from wholesalers

    High Accuracy Smt Pick Place Machine Led Bulb Assembly Ic Smd Making Machine

    Ask Lasest Price
    Brand Name : ETON
    Model Number : HT-E8S-1200
    Certification : CE,SIRA,CCC,ISO
    Price : EXW USD 48000/sets
    Payment Terms : T/T, L/C
    Supply Ability : 50 sets per mouth
    Delivery Time : 30 days after deposit
    • Product Details
    • Company Profile

    High Accuracy Smt Pick Place Machine Led Bulb Assembly Ic Smd Making Machine

    High Accuracy led bulb assembly IC smd making machine pick and place machine


    Product details
    1. Precision mounting head system
    The mounting method of 8 nozzle heads, group picking and separate placing / separate picking and separate placing can meet the mounting requirements of different components.
    Each nozzle head is independently controlled by an independent servo motor to reduce feeding and ensure mounting accuracy at a higher speed than the stepper motor.
    2. High precision imported screw
    The X and Y axis adopts high-end magnetic linear motor to control the screw, and the Z axis adopts panasonic servo motor to control and drive, with ultra-high acceleration performance and stable movement speed to ensure the accuracy and stability of each step of mounting.

    Scope of application
    Lamps and lanterns: fluorescent lamp, bulb lamp, ceiling light, panel light, cast light lamp, mining lamp, down light, etc
    Lighting: soft light tube, hard tube, advertising module, etc
    Pasting class: LED watch pasting

    HT-E8S
    PCBPCB length widthMax:1200*300mm min:100*100mm
    PCB thickness0.5~5mm
    PCB clampingAdjustable pressure pneumatic
    Mounting mode

    ØGroup to picking and separate to placing
    ØSeparate to picking and separate to placing

    O.S.systemWindows 7
    softwareR&D independently
    displayTouch screen monitor
    Input deviceKeyboard , mouse

    Vision

    system

    No.of camera

    2sets of imported camera
    Vision for the alignment identification,mark correction

    Mounting precision0.02mm(repeat precision)
    Mounting height<36mm
    Mounting speed40000CPH
    Components space0.2mm
    No.of feeders station30PCS
    No.of nozzles8PCS
    Power380AC 50HZ
    Power consumption4KW
    Conveyor transmissionMax length:1200mm
    Transmission speed>500mm/sec
    Transmission directionBoth direction
    Transmission modeAuto online drive
    Air pressure>5.0kg /cm²
    Electrical controlIndependent research and development by ETON
    Motion control card module 1setIndependent research and development by ETON
    X,Y,X axis drive wayServo motor control for X,Y,Z axis
    Feeding wayElectric feeder with double motor



    Company information
    Shenzhen Eton Automation Equipment co., LTD. is a professional manufacturer of pick and place machine. Our company independently research, development, design and manufacturer a set of high -speed good quality SMT pick and place machine. And we received a number of patents issued by the state certificate and support. Nowadays, we have served many factories and enjoyed good reputation.



    Honour show
    ETON advanced technology and innovation drives the revolution of market rapidly ,and obtains a number of intellectual property technologies.
    Including 9 invention patents,112practical patents,12 software copyrights.

    Logistics and delivery
    Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.
    Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.


    FAQ:
    1.How many cameras does the machine have?
    There are two sets of imported cameras.Using exclusive patent technology:vision for the flight identification,Mark correction.
    2.What is the direction of transmission of machines?
    The transmission direction of this machine is both direction.
    3. What kind of driving mode does the XYZ axis adopt?
    X axis is magnetic liner motor,Y axis and Z axis is servo motor,very good performance and high accuracy.
    4. What is the mounting mode?
    Group to picking and separate to placing,Separate to picking and separate to placing.
    5.Is your software interface in English?
    English interface and Chinese interface are both available.
