    Visual Camera Pick And Place Machine LED Electronic Products Machinery Feeders Station

    Ask Lasest Price
    Brand Name : ETON
    Model Number : HT-XF
    Price : FOB USD 56000/sets
    Payment Terms : T/T
    Supply Ability : 50 sets per mouth
    Delivery Time : 30 days after deposit
    Certification : ccc,ce,rise
    • Product Details
    • Company Profile

    Visual Camera Pick And Place Machine LED Electronic Products Machinery Feeders Station

    HT-XF Dual-purpose LED professional high speed mounter


    Performance introduction


    High Speed and High Precision

    This special Mounter has a speed of 150000~170000 CPH.Can save space, labor costs, management costs

    No. Of feeder station:34PCS nozzles:34PCS


    Good durability

    Using High Stability Electronic Dual Motor

    The wear resistance of screw rod is not easy to deviate and has high accuracy.

    The guide rail has strong bearing capacity and high stability.

    High-quality hardware configuration for 24-hour machine operation.





    Features

    Apply to the 0.6m,0.9m,1.2m LED rigid PCB and 0.5m,1m flexible strip.

    17 nozzles for each mounting module,part A or B can be mounted separately synchronously.

    Exclusive patent technology:group to pick and group to mount


    HT-XF
    PCBPCB length widthMax:330*1200mm min:90*330mm
    PCB thickness0.5~5mm
    PCB clampingAdjustable pressure pneumatic
    Mounting modeGroup to take and group to mount
    O.S.systemWindows 7
    softwareR&D independently
    displayLED monitor
    Input deviceKeyboard , mouse

    Vision

    system

    No.of camera

    5 sets of imported camera

    Vision alignment,mark correction

    Mounting precision0.02mm(repeat precision)
    Mounting height<15mm
    Mounting speed150000~170000CPH
    ComponentsLED 3014/3020/3528/5050 and resistors,capacitors ,bridge rectifiers.
    Components space0.2mm
    No.of feeders station34PCS
    No.of nozzles34PCS
    Power220AC 50HZ
    Power consumption5KW
    Conveyor transmissionMax length:1200mm
    Transmission speed>500mm/sec
    Transmission directionSingle (left to right or right or left)
    Transmission modeAuto online drive
    Position modeOptical
    Air pressure>5.0kg /cm²
    Electrical controlIndependent research and development by ETON
    Motion control card module 1setIndependent research and development by ETON
    X,Y,X axis drive wayServo motor control for X,Y,Z axis
    Feeding wayElectric feeder with double motor

    FAQ

    1, What’s the terms of payment? What about the trade term?

    T/T is OK. You can choose FOB Shenzhen.

    2, What is the delivery date?

    We will deliver the goods after 30 days' deposit.

    3,What mode of transport does the goods adopt?

    Our mode of transportation is very flexible.Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.

    4,What is the direction of transmission of machines?

    The transmission direction of this machine is single direction.From left to right or from right to left.

    5, How about your operating system?

    The operating system is Windows 7. The software is developed independently. It supports Chinese and English operation interface. And It has simple structure and is easy to operate.
