    High Quality Electronic Products Machinery LED Light Making SMT Mounting Machine

    Ask Lasest Price
    Brand Name : ETON
    Model Number : HT-E5D
    Price : FOB USD 76000~86000/sets
    Payment Terms : L/C, T/T
    Supply Ability : 50 sets per mouth
    Delivery Time : 30 days after deposit
    Certification : ccc,ce,rise
    • Product Details
    • Company Profile

    High Quality Electronic Products Machinery LED Light Making SMT Mounting Machine

    led light making machine Electronic Products Machinery Visual camera smart feeder


    Features


    HT-E5D led light making machine with Dual system,dual module multifunctional mounter.to produce two different products at same time.

    HT-E5D led light making machine Mounting components:LED,capacitors,resistors,IC,shaped components,etc.

    HT-E5D led light making machine Component:min.size 0402 max.height 36 mm.

    HT-E5D led light making machine Application: power driver.electric board.lens.linear bulb.household appliance etc.

    HT-E5D led light making machine adopts the method of Group to picking and separate to placing,Separate to picking and separate to placing.Each head can be controlled independently, and Flexible mounting of various components.

    HT-E5D led light making machine with 4 sets of imported cameras, synchronously recognize, effectively ensure mounting speed and precision.vision for the flight identification,mark correction.


    reference configuration


    1. Control system: industrial computer + precision motion control card + touch screen monitor

    2. Software system: Chinese and English operating system R&D independently by ETON.

    3. Sport motor: panasonic original motor

    4. Mounting nozzle: independently developed several types of nozzles.

    5. Sliding device: precision screw rod and linear guide rail.

    6. Visual device: MARK point recognition

    7. Feeding way:Electric feeder with double motor





    Exclusive Patented Technology

    Electronic feeder feeding system

    Vision alignment flight identification,mark correction

    Non-stop material re-loading function

    auto-optimization after coordinates generated ,etc



    HT-E5D led light making machine
    PCBPCB length widthMax:500*300mm min:100*100mm
    PCB thickness0.5~3mm
    PCB clampingElectric clamping + Adjustable pressure pneumatic
    Mounting mode

    Group to picking and separate to placing

    Separate to picking and separate to placing

    O.S.systemWindows 7
    softwareR&D independently
    displayTouch screen monitor
    Input deviceKeyboard , mouse

    Vision

    system

    No.of camera

    2sets of imported camera

    Vision for the alignment identification,mark correction

    Mounting precision0.02mm(repeat precision)
    Mounting height<36mm
    Mounting speed80000CPH
    Components space0.2mm
    Power380AC 50HZ
    Power consumption8KW
    Conveyor transmissionMax length:500mm
    Transmission speed>500mm/sec
    Transmission directionBoth direction
    Transmission modeAuto online drive
    Air pressure>5.0kg /cm²
    Electrical controlIndependent research and development by ETON
    X,Y,X axis drive wayHigh-end magnetic linear machine + Servo motor control for X,Y,Z axis
    Feeding way
    Feeding systemNo.of feeders stationDuel mode.totally 60
    No.of nozzlesDual mode.totally 16
    Feeding wayElectric feeder with double motor

    Packaging and Delivery

    Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.

    Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.



    Certificate of honor

    ETON advanced technology and innovation drives the revolution of market rapidly ,and obtains a number of intellectual property technologies.and rated as “shenzhen high-tech enterprise” “china high-tech enterprise” “shenzhen top brand” “2015 LED technology innovation award” “the 4th China LED first innovation award”.



    Partners&project cases


    Attention

    1. Before using the Pick and Place machine, you must understand the basic parameters of the placement machine;

    2. Before running the Pick and Place machine, the operator should do a comprehensive inspection of the machine.

    3. According to the boot operation sequence to implement the Pick and Place machine, there must have a detailed machine operation instructions;

    4. It is necessary to conduct regular troubleshooting and maintenance work on the Pick and Place machine in a timely manner.


    Remarks

    1.Payment terms: Deposit 30% in advance,the balance 70% should be paid before shipment by T/T.

    2.Delivery time: 30 days after deposit.

    3.Warranty: 1 year.(including spare parts)
