    Top Lead Free SMT Reflow Oven High Precision Temp Control With Ten Heating Zones

    Ask Lasest Price
    Brand Name : ETON
    Model Number : HT-R10
    Certification : CE ISO CCC
    Price : USD 1000-10000
    Payment Terms : T/T, Western Union
    Supply Ability : 50 unit per mouth
    Delivery Time : 1-2 weeks
    • Product Details
    • Company Profile

    Top Lead Free SMT Reflow Oven High Precision Temp Control With Ten Heating Zones

    Top lead free reflow oven with ten heating zones


    Function :

    Reflow soldering is mainly used with SMT process technology, in the SMT process, is the main purpose of reflow soldering will stick with components of the PCB board inside the orbit of reflow welding machine, after cooling, heating, heat preservation, welding, solder paste from cream after high temperature into a liquid, then through cooling into solid form, so as to realize the role of SMD electronic components and PCB welding.


    Introduction:

    The brand computer and Siemens PLC intelligent control system, high precision temperature control is ± 1-2 (if the computer crash accident, it can realize off-line work, do not affect production) and to ensure that the control system is stable and reliable;
    Windows XP operating interface with powerful and simple operation.
    In order to ensure safety and reliability, the cylinder body can be lift up automatically.
    Device is equipped with mesh belt, transport smoothly, no shaking and no deformation, which ensure smooth PCB transport. Synchronous guide transmission mechanism and automatic SMT machine online connection ensure that guide adjustable wide precision and high service life.
    Automatic control lubrication system and automatic lubrication transmission chain.
    All heating zone control by computer PID(upper temperature zone and lower temperature zone implementation independent temperature control, that means it can divide temperature area heat, in order to reduce starting power)
    Net/chain transmission by computer to carry out the whole closed loop control, which can meet different kinds of PCB production at the same time.
    With fault sound and light alarm function.
    With leakage protector, ensure that the operating personnel and control system security.
    The built-in UPS and automatic delay shutdown system guarantee return welder in power or overheat do not damaged PCB and the machine.
    The German ERSA world leading microcirculation heating mode, and the upper and lower independent air microcirculation system, temperature uniformity and thermal compensation high efficiency, high efficient supercharged accelerated air duct, greatly improve the circulating hot air flow, heat up temperature quickly (about twenty minutes), thermal compensation for high efficiency, high temperature welding and curing;
    The upper and lower every temperature zone with independent temperature inductive sensor, real-time monitoring and compensation every temperature zone balance;
    Have password administration of the operating system, to prevent the irrelevant personnel changes to the process parameters, operation records management traceability process parameters change process, improve the management convenient. For storing user existing temperature speed setting and Settings of the temperature curve, and can be used for all data and curve printing;
    Integrated control window, the computer switch, test curve, print curve and data transmission are easily operation, humanized design. Equipped with three-channel temperature curve online testing system, may at any time to check welding objects by the actual temperature curve (without the other match temperature curve tester);
    From international technology quick cooling system, use a magnifying glass type efficient rapid cooling, cooling speed can reach 3.5 ~ 6 / SEC, management is very convenient; The outer forced cooling device, ensure that spot crystal effect (Option selected items, the standard configuration for forced natural air cooling).

    Specification:

    ModelET-R10

    Heating System

    Number of heating zonesUp 10/ bottom 10
    Number of cooling zones2
    Length of heating zones3700mm
    Heating modeHot air
    Cooling ModeForced air cooling
    Exhaust Volume10m³/min * 2 exhausts

    Conveyor System

    Max. Width of PCB400mm
    Mesh belt width450mm
    Transmission DirectionL→R(option: RL)
    Transmission Net Height900±20mm
    Transmission typeMesh and chain
    Range of rail width50-400mm
    Conveyor speed0-2000mm/min
    Auto/manual LubricationStandard
    Fixed rail sideFront rail fixed(option: rear rail fixed)
    Components highTop and bottom 25mm

    Control system

    Power supply5 line 3 phase 380V 50/60HZ
    Total power58KW
    Starting power50KW
    Normal power consumption10KW
    Warming time20 mins
    Temp. setting rangeFrom room temp. To 300℃
    Temp. control methodPID close loop control & SSR driving
    Temp. control precision±1℃
    Temp. deviation on PCB±2℃
    Data storageProcess Data and status storage(80GB)
    Nozzle plateAluminum Alloy Plate
    Abnormal AlarmAbnormal temperature (extra-high/extra-low temperature)
    Board dropped alarm

    Tower light:

    Yellow-warming, Green-normal, Red-abnormal


    General

    Dimension(L*W*H)5400*1320*1490mm
    Weight2300kg
    ColorComputer gray

    Company profile :


    ShenZhen ETON Automation Equipment Co.,LTD.is a leading manufacturer of automatic SMT machine.In 2011,set up ShenZhen Eton Automation Equipment Co.,Ltd.In 2011,HT-12 series began selling.In 2011,HT-E3 was complete research and development (Eton 3 generation machine).


    Project Cases :



    Our Services

    1. offer detail manual user .

    2. customer to our factory study and training .

    3. offer overseas service : can send engineers

    4. to customer factory for install
