Dual-Purpose professional high-speed mounter HT-F7

Technical parameter:

PCB Length Width

Max:1200*330mm min:80*330mm

PCB Thickness

0.5~5mm

No.of Camera

5 sets of imported camera

Mounting Height

<15mm

Mounting Speed

100000~150000CPH

Components

LED3014/3020/3528/5050 and resistor,capacitors,bridge rectifiers

No.of Feeders Station

72PCS

No.of nozzles

36PCS

Power

220AC 50Hz

Power Consumption

5KW

Length*Width*Height

1600mm*1900mm*1550mm

Total Weight

1100Kg

Application:

The high speed pick and place machine HT-F7 is very suitable for tube,panel,flexible strip,linear light etc.

It will improve your production efficiency,save labor,space,power etc.

Company Introduction:

ShenZhen ETON Automation Equipment Co.,LTD.is a leading manufacturer of automatic high-speed pick and place machine focusing on “High efficiency Low consumption”in the world,meanwhile ETON also the largest high-tech manufacturer in Chine with strong capability of design,R&D,manufacturing,sales&service,and rates as “Shenzhen high-tech enterprise”“China high-tech enterprise”“Shenzhen TOP Brand”“2015LED Technology Innovation Award”“The 4th China LED First Innovation Award”“Industry Special Contribution Award”“Double soft enterprise”etc.

ETON advanced technology and innovation drives the revolution of market rapidly,and obtains a number of intellectual property technologies,including 9 invention patents,112 practical patents,12 software copyrights,moreover,ETON has invented the fastest automatic pick and place machine with speed 170000CPH,which save mach labors and space of production,got large market share in USA,KOREA,INDIA,GERMANY,EGYPT,TURKEY,VIETNAM,TUNISIA,THAILAND more than 20 countries.

FQA:

1.Who is your client?

We have exported machine to different countries,such as India,Egypt,Korea,Turkey,Brazil etc.

Such as FSL,ETI,KONKA,OPPLE,MLS are our client,In india such as RK,Surya,skyquad are our client.

2.How is the warranty?

Standard warranty is one year,during warranty,any parts need to be repaired and replaced will be free.

3.How is the breakdown rate of machine?

Our machine is very stable,the breakdown rate is less than 0.001.

4. Is your software interface in English?

English interface and Chinese interface are both aviable.

Exhibition & Certification:

ETON advanced technology and innovation drives the revolution of market rapidly,we hold exhibitions at home and abroad every year ,and obtains a number of intellectual property technologies,including 9 invention patents,112 practical patents,12 software copyrights,moreover.

For SMT factory setup,we can do for you:
1. We provide full SMT solution for you
2. We provide core technology with our equipments
3. We provide the most professional tech service
4. We have wealthy experience on SMT factory setup
5. We can solve any question about SMT

Shenzhen ETON Automation Equipment Co.,LTD. was establised in 2007,possess more than 300 staff at present and cover an area of more than 20000 square meters,is the largest leading manufacturer of high-speed pick and place machine and SMT machine for LED light production and Electronic field,which is also a high-tech enterprise and top brand well-known in China with good reputation.


  ETON invented the fastest automatic pick and place machine with speed 150000CPH,which is the fastest machine in the world,awarded many global first technology patent,also invented the global first machine for any length of 1M 5M 50M 100M 500M flexible LED strip,won large market in USA,KOREA,INDIA,GERMANY,EGYPT,TURKEY,VIETNAM,TUNISIA ETC.


  Since the establishment of the company, with the green and energy-saving development trends of global illumination and rapid development of LED industry and its requests for the manufacturing craft, ETON has seized the opportunity and risen quickly, they have independently researched、designed、manufactured a set of quicker、more stable、more optimal LED fully automatic, high speed, energy-saving chip mounter and multi-function chip mounter, which have been highly recognized in the industry for its absolute advantage in speed, stability and capacity, at the same time, it have solved the offset and fling material issues when producing 1.2 meters, 1.5 meters lamp plates and wireless long FPCB and shaped component at a high speed. ETON has passed ISO9001 quality management system certification and has obtained more than one hundred of patents and certificates, including for utility model, personal invention, software copyright and so on. We have established cooperative relationship with well-known enterprises at home and abroad, such asMLS,OPPLE,NVC,Navigation,PAK,ETI,FSL, Home Lighting,Yangguang Lighting, XSY, Sansi, India RK, India SURYA, Vietnam RANGDONG, Egypt FUTEK etc..

  Our products have been exported to more than 20 countries and regions, including Korea, India, Vietnam, Tunisia, Egypt, Turkey and so on. Meanwhile, the company has created customer service center, where records every customer and the sale of every set of machine permanently. Its existence can timely solve customer’s questions when using it, which truly provides the convenience and assurance for our customers.

  “High efficiency” “High quality” and “Stability” are the core technology of ETON,technology innovation and strict quality control,with excellent service,ETON has grown into the outstanding worldwide brand of SMT machine with good reputation.
