smd mounting machine pick and place machine for 0201 SOP with 80000CPH

    Buy cheap smd mounting machine pick and place machine for 0201 SOP with 80000CPH from wholesalers

    Buy cheap smd mounting machine pick and place machine for 0201 SOP with 80000CPH from wholesalers
    • Buy cheap smd mounting machine pick and place machine for 0201 SOP with 80000CPH from wholesalers

    smd mounting machine pick and place machine for 0201 SOP with 80000CPH

    Ask Lasest Price
    Brand Name : ETON
    Model Number : YT-20
    Certification : ccc,ce,risa
    Price : FOB USD 76000/sets
    Payment Terms : L/C, T/T
    Supply Ability : 50 sets per mouth
    Delivery Time : 30 days after deposit
    • Product Details
    • Company Profile

    smd mounting machine pick and place machine for 0201 SOP with 80000CPH

    smt pick and place machine led light,pcb mounting machine,led light making machine with double module,led making machine,led production machine

    Patented Technology of led making machine
    Electronic feeder feeding system
    Vision alignment flight identification,mark correction
    Non-stop material re-loading function
    Auto-optimization after coordinates generated ,etc.

    Technical parameter of SMD mounitng machine

    PCB length width

    Double module&Double rail:
    MAX:500x300mm(Non-omnidirectional 640x300mm) MIN:50x50mm
    Single module&Single rail:
    MAX:500x540mm (Non-omnidirectional 640x540mm) MIN:50x50mm

    Components

    0201 IC 50x50mm
    Mounting Height:20mm

    Mounting speed

    70000 CPH
    (Under the best conditions for our company)

    Mounting precision±0.03mm(Repeat precision)
    No. Of feeders station32PCS(Double material feeder, can load 64 trays of material)
    PowerAC380 50Hz
    Air supply0.4-0.6Mpa (4-6Kgf/㎡)
    Vacuum detectionIndependent vacuum detection of reclaiming material
    DimensionL 2795 X W 1497 X H 1687
    Total weight1700kg


    Pictures of pick and place machine


    Certificate of honor
    ETON advanced technology and innovation drives the revolution of market rapidly ,and obtains a number of intellectual property technologies.and rated as “shenzhen high-tech enterprise” “china high-tech enterprise” “shenzhen top brand” “2015 LED technology innovation award” “the 4th China LED first innovation award”.


    Exhibition

    Packaging & Shipping


    Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.
    Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.

    Our Services

    we will send our engineer to your factory to install machine and training freely.
    We have service office in india,and have indian engineer in delhi and mumbai.Can support quickly.
    Standard warranty is one year,during warranty,any parts need to be repaired and replaced will be free.
    Pre-Consultation: provides professional SMT solutions for the full line.
    ■ Factory Warranty: One-year warranty factory service.
    ■ Installation: On-site installation and commissioning, to ensure smooth production.
    ■ Software Upgrade: offers lifetime free software upgrades for all products


    Attention
    1. Before using the Pick and Place machine, you must understand the basic parameters of the placement machine;
    2. Before running the Pick and Place machine, the operator should do a comprehensive inspection of the machine.
    3. According to the boot operation sequence to implement the Pick and Place machine, there must have a detailed machine operation instructions;
    4. It is necessary to conduct regular troubleshooting and maintenance work on the Pick and Place machine in a timely manner.


    Welcome contact with me to get more details!
