    6KW SMT Mounting Machine Automatic Two Materials Are Produced Simultaneously

    Ask Lasest Price
    Brand Name : ETON
    Model Number : RT-2
    Certification : CCC/CE
    Price : USD 67000-75000 Unit/Units
    Payment Terms : L/C, T/T
    Supply Ability : 50 Unit/Units per month
    Delivery Time : 15-30 days
    • Product Details
    • Company Profile

    6KW SMT Mounting Machine Automatic Two Materials Are Produced Simultaneously

    6KW SMT Mounting Machine Automatic Two Materials Are Produced Simultaneously


    80000 cph pick and place machine automatic two materials are produced simultaneously


    Product Description

    1. with double module,total 20 head,each part 10 head, can produce two types of products at the same time.
    2. The X axis is magnetic liner motor,Y axis and Z axis is servo motor,very good performance and high accuracy.
    3. It's intelligent,can produce different types of LED light and electric board,such as bulb ,strip, Panel, Downlight, streetlight,power driver, other electronic boards, etc
    4. Its high precision(accuracy),apply to LED chips,resistor,capacitor,IC,shaped components etc.
    Dimension (L*W*H)
    1200*1930*1500mm
    Total weight
    2500kg
    PCB Length width
    Max:450*300mm Min:80*80mm
    PCB thickness
    0.1-6mm(If<0.6mm need jig)
    PCB clamping
    pneumatic
    No.of feeders station
    64 PCS
    No.of head
    20 PCS
    Mounting speed
    80000 CPH
    Power
    AC 380 V
    Operating environment
    6 KW
