80000 CPH Pick And Place Machine LED SMT Mounter Production Line

    Buy cheap 80000 CPH Pick And Place Machine LED SMT Mounter Production Line from wholesalers

    Buy cheap 80000 CPH Pick And Place Machine LED SMT Mounter Production Line from wholesalers
    • Buy cheap 80000 CPH Pick And Place Machine LED SMT Mounter Production Line from wholesalers

    80000 CPH Pick And Place Machine LED SMT Mounter Production Line

    Ask Lasest Price
    Brand Name : ETON
    Model Number : RT-2
    Certification : CCC/CE
    Price : USD 67000-75000 Unit/Units
    Payment Terms : L/C, T/T
    Supply Ability : 50 Unit/Units per month
    Delivery Time : 15-30 days
    • Product Details
    • Company Profile

    80000 CPH Pick And Place Machine LED SMT Mounter Production Line

    80000 CPH Pick And Place Machine LED SMT Mounter Production Line


    80000CPH multifunctional pick and place machine RT-2 LED SMT Mounter LED Production Line


    Product Description

    Dimension (L*W*H)
    1200*1930*1500mm
    Total weight
    2500kg
    PCB Length width
    Max:450*300mm Min:80*80mm
    PCB thickness
    0.1-6mm(If<0.6mm need jig)
    PCB clamping
    pneumatic
    No.of feeders station
    64 PCS
    No.of head
    20 PCS
    Mounting speed
    80000 CPH
    Power
    AC 380 V
    Operating environment
    6 KW

    Features

    1. with double module,total 20 head,each part 10 head, can produce two types of products at the same time.
    2. The X axis is magnetic liner motor,Y axis and Z axis is servo motor,very good performance and high accuracy.
    3. It's intelligent,can produce different types of LED light and electric board,such as bulb ,strip, Panel, Downlight, streetlight,power driver, other electronic boards, etc
    4 .Its high precision(accuracy),apply to LED chips,resistor,capacitor,IC,shaped components etc.


    80000 CPH Pick And Place Machine LED SMT Mounter Production Line


    Pcaking&Shipping


    FAQ

    1. What is the approximate delivery time?
    Delivery time is 30 days


    2. What kind of service I can have, if I buy machine from ETON ?
    We will arrange training and study for engineers free of charge

    3. What's about the guarantee of the machines?
    The maintenance:during warranty,any parts need to be repaired or replaced will be free. We will take the responsibility of the machines from A to Z.

    4. Is the machine difficult to operate?
    The machine uses English and Chinese interface, very simple and easy to operate, and the machine supports remote control .

    5. What are the main LED products o our machines for?
    There are different machines in our company and different machines apply to different LED lights. The main products we can apply: bulb,tube strip lamp panel. Down light, street light, ceiling light. wall washer light and so on.
