led strip making machine for 50M with 250000CPH led pick and place machine

Pick and place Machine main features

High: mounting speed: 250000CPH(in good conditions) mounting speed

High accuracy: the guide rail adopt magnetic linear motor and servo motor

Four modules and two arms, 68 feeders station and 68 heads

mounting mode of group to pick and group to place

5 sets of digital camera, vision alignment and mark correction

Apply to any length of led flexible strip, including 5M, 10M, 25M, 50M, 100M and so on. There is a platform to supports the PCB soft board of LED flexible strip.

software is researched and developed independently by ETON which has two language version, English and Chinese. it is also very easy to operate.

Pick and place Machine main parameter

The applications and components of HT-T9 SMT pick and place machine

PCB SIZE: 250 mm * any length

APLICATIONS: 5 M, 10 M, 25 M, 50M, 100 M or any length of LED flexible strip and ROLL TO ROLL .

COMPONENTS: LED 3014 / 3020 / 3528 / 5050 and resistors, capacitors, bridge rectifiers etc.

The semi automatic SMT production line of HT-T9 SMT pick and place machine

Because the Semi automatic production line has the lower Costs,the requirement of space is smaller and production is relatively flexible. Therefore, it is suitable for most factories.

The delivery and transport

We install the international standard and pack the machine in three steps:

The first step: packing the machine with foam cotton and stretch film to protect the outside of the machine

The second step: Vacuum packaging, put the desiccant in a vacuum bag to prevent moisture, use straps to secure the machine

The third step:professional wooden box packaging

In addition, we can choose land transportation, air transportation and sea transportation according to customers' needs.

Shenzhen ETON Automation Equipment Co.,LTD. was establised in 2007,possess more than 300 staff at present and cover an area of more than 20000 square meters,is the largest leading manufacturer of high-speed pick and place machine and SMT machine for LED light production and Electronic field,which is also a high-tech enterprise and top brand well-known in China with good reputation.


  ETON invented the fastest automatic pick and place machine with speed 150000CPH,which is the fastest machine in the world,awarded many global first technology patent,also invented the global first machine for any length of 1M 5M 50M 100M 500M flexible LED strip,won large market in USA,KOREA,INDIA,GERMANY,EGYPT,TURKEY,VIETNAM,TUNISIA ETC.


  Since the establishment of the company, with the green and energy-saving development trends of global illumination and rapid development of LED industry and its requests for the manufacturing craft, ETON has seized the opportunity and risen quickly, they have independently researched、designed、manufactured a set of quicker、more stable、more optimal LED fully automatic, high speed, energy-saving chip mounter and multi-function chip mounter, which have been highly recognized in the industry for its absolute advantage in speed, stability and capacity, at the same time, it have solved the offset and fling material issues when producing 1.2 meters, 1.5 meters lamp plates and wireless long FPCB and shaped component at a high speed. ETON has passed ISO9001 quality management system certification and has obtained more than one hundred of patents and certificates, including for utility model, personal invention, software copyright and so on. We have established cooperative relationship with well-known enterprises at home and abroad, such asMLS,OPPLE,NVC,Navigation,PAK,ETI,FSL, Home Lighting,Yangguang Lighting, XSY, Sansi, India RK, India SURYA, Vietnam RANGDONG, Egypt FUTEK etc..

  Our products have been exported to more than 20 countries and regions, including Korea, India, Vietnam, Tunisia, Egypt, Turkey and so on. Meanwhile, the company has created customer service center, where records every customer and the sale of every set of machine permanently. Its existence can timely solve customer’s questions when using it, which truly provides the convenience and assurance for our customers.

  “High efficiency” “High quality” and “Stability” are the core technology of ETON,technology innovation and strict quality control,with excellent service,ETON has grown into the outstanding worldwide brand of SMT machine with good reputation.
