    ETON smt assembly equipment small smt pick and place machine in SMT production line

    Ask Lasest Price
    Brand Name : ETON
    Model Number : YT-101S
    Certification : ccc,ce,risa
    Price : FOB USD 46000/sets
    Payment Terms : L/C, T/T
    Supply Ability : 50 sets per mouth
    Delivery Time : 30 days after deposit
    • Product Details
    • Company Profile

    ETON smt assembly equipment small smt pick and place machine in SMT production line

    ETON smt assembly equipment small smt pick and place machine in SMT production line

    Features of SMT machine



    Flexible production:Fixed flight vision recognition camera,components with less than 40*40mm or height less than 20mm can be used to high-speed and high-precision,IC tray feeder support.
    Intelligent electric feeder:support YT series double head intelligent electric tape reel feeder,by optically correcting the feeding position of the component.it can achive stable,accurate and high speed feeding.
    High reliability :high speed precision head flight vision camera capture the image of placement accordingly,improve the speed the speed and accuracy of placement.

    Technical parameter of SMD mounitng machine


    Camera2 sets;head flight vision recognition component;vision alignment+Mark correction
    Heads10 pcs
    feeder station32 pcs
    PCB Size500*350mm
    pcb thickness0.5-4.5mm
    Driver wayhigh-end magnetic linear motor + servo motor
    mounting speed40000CPH
    Power280AC 50 HZ 4kw


    Pictures of pick and place machine


    SMT PRODUCTION LINE SOLUTION



    SMT production process
    processStep.details
    Step 1Solder paste PrintingOperate the stencil printer to print the solder paste onto the PCB
    Step 2Mounting PartThe PCB board that has been brushed with solder paste will be sent to the pick and place machine for automatic mounting, and the pick and place machine will automatically pick components and place on PCB
    Step 3Reflow SolderingThe PCB board be mounted with components is sent to reflow oven,reflow oven will heat and welding the components with solder paste on PCB.
    Step 4TestingCheck whether the PCBA is misaligned or shift.



    Our Partners



    ETON advanced technology and innovation drives the revolution of market rapidly,and obtains a number of intellectual property technologies,including 9 invention patents,112 practical patents ,12 software copyrights,which save much labors and space of production ,got large market share in USA ,KOREA,INDIA,GERMANY,EGYPT,TURKEY,VIETNAM,TUNISIA,THAILAND more than 20 countries.

    Our company


    After services of ETON


    1. Before order:
    We will support professional suggestion of SMT line
    We will recommend the best module according to the products
    We will supply best quotation with factory price
    2. After order:
    Machine will have good test and aging before shipping
    We support machine free installation and training, special time we support online training, and video teaching.
    We have Professional after-sales team, could solve problem as soon as possible
    Machine warranty is one year, during warranty, any parts need to be repaired and replaced will be free for clients.

    FAQ


    Q: Are you a trade company or a manufacturer?
    We are an professional manufacturer specialized in Screen Printer,SMT Machine, Pick and Place Machine, Reflow Oven, SMT Production line and other SMT Products.
    Q: What is your delivery date?
    The delivery date is about 20 days upon the full payment.
    Q: What is your payment terms?
    100% payment before delivery or 50% deposit in advance and the rest before shipment.
    Q: How is the warranty?
    1. Every machine will be checked carefully before shipping out. Buyers should check the package once receiving.
    2. The complete machine has a warranty period of 12 months from delivery and lifetime maintenance service.
    3. We provide online Q/A and troubleshooting support and technical advice service. Provide one to one after-sale service.

    What are your advantages?
    Our company stick to five level management policy: sincere business, focus on R&D, manufacturing intentions, considerate service, customer trust
