68 heads high speed pick and place machine save cost SMT production line

Features

1. High-end magnetic linear motor + Panasonic Servo Motor

2. 64 heads, 64 feeder stations

3. Group to pick and group to mount

4. Vision alignment, Mark Correction

5. Capacity can Reach 200000 CPH

HT-F9 Main parameters

Application

HT-F9 is a very high speed pick and place machine. It’s specialized for big quantity production of LED tube light, panel light, strip light.

HT-F9 is for double module, consisting of two modules interact to mount around, each module can be installed nozzle 32, part A or part B can be mounted separately or synchronously.

ETON Company

Since the establishment of Eton company, we have successively reached strategic cooperation with many domestic and foreign companies. And has achieved everyone's unanimous recognition and praise. In the field of high-speed placement machines has become a leading Chinese brand.

Before 2019, Eton company has established Shenzhen Headquarters, East China Zhejiang Office, Zhongshan Office and Xiamen Office in China. And has established a Delhi office in abroad. In the near years, Eton plan to complete the office in East China and open new office in India and other countries.

FAQ

Q1:Is it safe during the delivery?
A:All the machine is packed safely, by standard strong wooden carton with vacuum package.

Q2: how is the breakdown rate of machine?
A:our machine is very stable, the breakdown rate is less than 0.001.

Q3:Does your machine have quality certificate?
A:Our machine have pass CE certificate, SIRA, ISO and have patent

Q4:Can you support whole SMT line?
A: Yes, we can provide whole line solution if you want. We are very professional on SMT field.

Shenzhen ETON Automation Equipment Co.,LTD. was establised in 2007,possess more than 300 staff at present and cover an area of more than 20000 square meters,is the largest leading manufacturer of high-speed pick and place machine and SMT machine for LED light production and Electronic field,which is also a high-tech enterprise and top brand well-known in China with good reputation.


  ETON invented the fastest automatic pick and place machine with speed 150000CPH,which is the fastest machine in the world,awarded many global first technology patent,also invented the global first machine for any length of 1M 5M 50M 100M 500M flexible LED strip,won large market in USA,KOREA,INDIA,GERMANY,EGYPT,TURKEY,VIETNAM,TUNISIA ETC.


  Since the establishment of the company, with the green and energy-saving development trends of global illumination and rapid development of LED industry and its requests for the manufacturing craft, ETON has seized the opportunity and risen quickly, they have independently researched、designed、manufactured a set of quicker、more stable、more optimal LED fully automatic, high speed, energy-saving chip mounter and multi-function chip mounter, which have been highly recognized in the industry for its absolute advantage in speed, stability and capacity, at the same time, it have solved the offset and fling material issues when producing 1.2 meters, 1.5 meters lamp plates and wireless long FPCB and shaped component at a high speed. ETON has passed ISO9001 quality management system certification and has obtained more than one hundred of patents and certificates, including for utility model, personal invention, software copyright and so on. We have established cooperative relationship with well-known enterprises at home and abroad, such asMLS,OPPLE,NVC,Navigation,PAK,ETI,FSL, Home Lighting,Yangguang Lighting, XSY, Sansi, India RK, India SURYA, Vietnam RANGDONG, Egypt FUTEK etc..

  Our products have been exported to more than 20 countries and regions, including Korea, India, Vietnam, Tunisia, Egypt, Turkey and so on. Meanwhile, the company has created customer service center, where records every customer and the sale of every set of machine permanently. Its existence can timely solve customer’s questions when using it, which truly provides the convenience and assurance for our customers.

  “High efficiency” “High quality” and “Stability” are the core technology of ETON,technology innovation and strict quality control,with excellent service,ETON has grown into the outstanding worldwide brand of SMT machine with good reputation.
