    high speed 90000CPH SMD surface mount pick and place machine in smt production line

    Ask Lasest Price
    Brand Name : ETON
    Model Number : HT-E8D-1200
    Certification : ccc,ce,risa
    Price : FOB USD 81000/sets
    Payment Terms : L/C, T/T
    Supply Ability : 50 sets per mouth
    Delivery Time : 30 days after deposit
    • Product Details
    • Company Profile

    high speed 90000CPH SMD surface mount pick and place machine in smt production line

    high speed 90000CPH SMD surface mount pick and place machine in smt production line


    Function of SMT pick and place machine


    Exclusive Patented Technology

    Electronic feeder feeding system

    Vision alignment flight identification,mark correction

    Non-stop material re-loading function

    Non-stop material re-loading function


    Features of SMD pick and place machine


    Vision system

    2 sets of imported camera

    Vision for the alignment identification,mark correction

    Visual recognition system can process the absorbed components into the required mounting angle through image recognition, and ensure the mounting accuracy, which can reach 0.02mm.


    Strong stability

    The use of dual motor electronic flying feeding ensures the mounting accuracy, stability and speed.


    High efficiency

    Dual system ,Two module ,16 nozzles totally,40 feeders station .

    Flight camera component identification method is used to maximize the mounting speed, and the maximum mounting speed is 80000 points per hour.


    Easy to maintain

    Support Chinese and English operation interface, easy to understand and learn

    Machine new equipment, powerful and easy to operate software, simple structure, easy maintenance, low power consumption.


    Technical parameter of pick and place machine



    Technical parameter
    PCB
    PCB length widthMax:1200*300mm min:100*100mm
    PCB thickness0.5~5mm
    PCB clampingAdjustable pressure pneumatic
    O.S.
    systemWindows7
    softwareR&D independently
    displayTouch screen monitor
    inputKeyboard mouse
    Feeding system
    No. of feeders stationDual mode ,totally 40
    No.of nozzlesDual mode,totally 16
    Feeding wayElectric feeder with double motor


    SMT Line


    Our Partners


    ETON advanced technology and innovation drives the revolution of market rapidly,and obtains a number of intellectual property technologies,including 9 invention patents,112 practical patents ,12 software copyrights,which save much labors and space of production ,got large market share in USA ,KOREA,INDIA,GERMANY,EGYPT,TURKEY,VIETNAM,TUNISIA,THAILAND more than 20 countries.


    Industrial Park



    Packaging & Shipping of SMT machine

    Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.

    Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.

    Our Services

    we will send our engineer to your factory to install machine and training freely.

    We have service office in india,and have indian engineer in delhi and mumbai.Can support quickly.

    Standard warranty is one year,during warranty,any parts need to be repaired and replaced will be free.


    FAQ


    What’s the terms of payment? What about the trade term?

    T/T is OK. You can choose FOB Shenzhen.


    How about your operating system?

    The operating system is Windows 7. The software is developed independently. It supports Chinese and English operation interface. And It has simple structure and is easy to operate.


    What is the delivery date?

    We will deliver the goods after 30 days' deposit.


    What mode of transport does the goods adopt?

    Our mode of transportation is very flexible.Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.


    What is the direction of transmission of machines?

    The transmission direction of this machine is single direction.From left to right or from right to left.
