    Dual system dual module 4 sets camera capacity 80000 CPH RT-2 pick and place machine

    Ask Lasest Price
    Brand Name : ETON
    Model Number : RT-2
    Certification : CCC, CE
    Price : USD 41000-61000
    Payment Terms : L/C, T/T
    Supply Ability : 50 sets per month
    Delivery Time : 30 days after deposit
    • Product Details
    • Company Profile

    Dual system dual module 4 sets camera capacity 80000 CPH RT-2 pick and place machine

    Dual system dual module 4 sets camera capacity 80000 CPH RT-2 pick and place machine


    The Feature of RT-2


    RT-2 is Dual system and dual module magnetic linear motor multifunctional pick and place machine.

    The power consumption of RT-2 is 6KW.

    RT-2 is able to produce two different products at the same time.

    The machine of RT-2 has 4sets of camera: vision alignment and Mark correction.

    The Optimum capacity will reach 80000CPH.

    RT-2 is the Enhanced version of RT-1.


    The Completed RT-2 SMT Production Line


    Solder paste printer machine: Put the solder paste on the PCB board

    Double-rail Conveyor: transmission the PCB board to pick and place machine

    Pick and place machine RT-2: mounting the components on the PCB board

    Reflow oven: heating the PCB board



    Technical parameter


    ModuleRT-2
    Length1200mm
    Width1930mm
    Height1500mm
    Total weight2500kg
    PCB Length width

    Double side, double track:

    Max: 450*300mm Min: 80*80mm

    Single side, single track:

    Max: 450*540mm Min: 80*80mm

    PCB Thickness0.1-6mm ( If <0.6mm need jig)
    SystemWindows 7
    DisplayTouch screen monitor
    Input deviceKeyboard, mouse
    Transmission speed1000mm/sec
    Mounting precision±0.04mm
    Transmission directionSingle( left→right or right →left )
    No. Of feeders station64PCS
    No. Of head20PCS
    Operating environment23℃±3℃
    Power consumption6KW
    X, Y, Z Axis drive wayHigh-end magnetic linear motor and serve motor
    Feeding wayElectric feeder with double motor
    Mounting componentscapacitors, resistors, IC, crystal, shaped component etc
    ApplicationsLED bulb, mining light, street light, panel light, table light, ceiling light etc.

    Company introduction


    ETON is the leading manufacturer of global photoelectric high speed pick and place machine, the products are exported to more than 20 countries and regions, including South Africa, Egypt, Turkey, Russia, Brazil, India and so on. ETON is not only in the leading position in the field of photoelectric high speed placement machines, but also has made breakthrough progress in the field of SMT high speed placement machines. ETON has obtained a number of intellectual property technologies.

    Shenzhen high-tech enterpriseShenZhen TOP Broad
    China high-tech enterpriseNational high-tech enterprise
    The 4th China Innovation Award2015 LED tech Innovation Award
