    24 Heads 90000 CPH LED Bulb Making Machine Multi Functional LED Mounting Machine

    Ask Lasest Price
    Brand Name : ETON
    Model Number : HT-E8D
    Certification : CCC, CE, SIRA
    Payment Terms : T/T
    Supply Ability : 50 sets/month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    24 Heads 90000 CPH LED Bulb Making Machine Multi Functional LED Mounting Machine

    Product Description

    HT-E8D-1200 is big machine for producing two pcb at the same time with 90000 CPH. Specially, it is suitable for max pcb size is 1200*300mm, suitcable for led tube/panel/led strip/bulb/lens/etc.

    ETON tech adjustable placement head. Component picking position can be adjusted. According to PCB pad.Apply to LED chip,capacitors, resistors,lens,IC,shaped components.etc and component-MIN size 0404,MAX height 15mm. The placement head adopt the method of two times picking and once placing. The placement time greatly minimized with the improved placement way, excellent optimum capacity reach 90000CPH.


    Technical parameter

    ModelHT-E8D
    Length3150mm
    Width2250mm
    Height1650mm
    Total Weight2500kg
    PCB size(L* W)Max:1200*300mm Min;100*100mm
    PCB Thickness05-5mm
    PCB ClampingAdjustable pressure pneumatic
    Mounting modeGroup picking and separately placing,separately picking and separately placing
    SystemWindows7
    SoftwareR&D Independently
    DisplayTouch screen monitor
    Input DeviceKeyboard, mouse
    No.of camera2setsDigital camera(Digital camera)
    ComponentsLED chip,capacitors,resistors,IC,shaped components,etc.
    No.of feeders station28PCS
    No.of nozzles12PCS

    Our Service

    Trade show and sales service

    We will provide the sales service though e-mail and exhibitions to communicate face to face , let you feel the real competitive products.

    After sales service

    Maintenance period:1 year.

    Visit customers regularly and gather information.

    Provide latest information about technology and equipment.


    ETON Profile

    Shenzhen ETON Automation Equipment CO., LTD. is one of very few high-tech manufacturers committed to provide "professional, high efficiency, low consumption" automatic high-speed SMT pick and place machine for customers,combining product development,production,sales and service as one. At present,as for the series "HT" high-speed and multi-functional machine,speed is the world's fastest. "Speed" and "Stability" are the core competencies of ETON,technology innovation and strict quality management principles coupled with excellent service , to enable us provide better professional full SMT solution continously and create superior value for our customers.


    FAQ

    1. If there is a problem with the machine,can it be repaired?

    A: Of course, the machine failure rate is 0.001 , and in addition to the warranty period, we also provide you with free maintenance 1-2 times a year.

    2. Is there any quality guarantee?

    A: We stick to quality first, client-oriented, Continuous improvement!

    3. Why choose us?

    A: We provide professional in SMT line for 11 years,with strong production and strong capacity and R&D team,Has provided a lot of clients with modern SMT production line solutions.
