Effectively SMEMA interface Max 260mm FPCB automatic printer machine
Machine configuration
● Programmable suspension printing head;
*Two sets of stepping motor drive, the pressure of front and rear
scraper can be adjusted separately to ensure the inconsistency of
front and rear printing caused by fatigue deformation of scraper
material;
*Effectively control the stroke, improve the printing efficiency,
and prevent the leakage of solder paste;
● Standard stainless steel scraper, unique design, improve the
service life of the blade;
● Downward vision alignment system;
● CNC guide rail adjustment;
● Industrial controlled computer,Windows XP interface operating
system;
● Built-in software diagnostic system;
● SMEMA interface.
Technical parameter
| Screen Frames | Min Size | 850mm |
| Max Size | 550mm |
| Thickness | 25~45mm |
| FPCB Min Size | 50mm |
| FPCB Max Size | 260mm |
| FPCB Thickness | 0.5~5mm |
| FPCB Warpage | Max. FPCB diagonal 1％ |
| Transport Height | 900±40mm |
| Transport Direction | Left-Right |
| Transport Speed | Max 1000mm/S Programmable (Adjustable) |
| Board Location | Support System | Platform jacking tension |
| Clamping System | Edge clamp fixed |
| Print head | Two independent motorized print heads |
| Squeegee Speed | 6~300mm/sec |
| Squeegee Pressure | 0~10Kg/cm2 |
| Squeegee Angle | 55°(Standard) |
| Squeegee Type | Stainless steel(Standard), plastic |
| Stencil Separation Speed | 0.1~20mm/sec Programmable |
| Cleaning System | Manual cleaning |
| Table Adjustment ranges | X:±5mm;Y:±5mm;θ:±2° |
| Machine |
| Repeat Position Accuracy | ±0.01mm |
| Printing Accuracy | ±0.025mm |
| Cycle Time | ≤9s (Exclude Printing & Cleaning) |
| Air Required | 4.5~6Kg/cm2 |
| Power Input | AC:220±10%,50/60HZ 1Φ 1.5KW |
| Control Method | PC Control |
| Machine Dimensions | 1754(L)X1249(W)X1600(H)mm |
| Machine Weight | Approx:600Kg |
| FPCB transport over plate height | 20mm |
Certificates
As an experienced manufacturer in SMT machine, we obtained a number
of intellectual property technologies, including 9 invention
patents, 112 practical patents, 12 software copyrights, with our
won R&D department for production and inspection. And also
earned the oversea certificates as CE, CCC, SIRA,
etc.
Shipping and Delivery
Land transportation: suitable for inland countries and it is affordable;
Air freight: for urgent good, and it is the most expensive transportation way;
Shipping: It’s suitable for heavy goods, and the convenience and lower cost
of shipping which is easy for clients to accept the arrival time of
the goods.
FAQ
Q. How many hours does the machine can operate per day?
A.Machine can work whole day. But for longer using life, we suggest
you to have 1 hour or 2 hours off per day.
Q. Is the machine easy to operate?
A. Yes, our machine is very intelligent and easy to operate, like
the intelligent phone, also the software is made by our company, so
we know how to make it more intelligent and operate friendly.
Q.How can I make inspection when something wrong with the machine?
A. Well, the inspection is taken by our professional engineer to
check and modulate the machine, if you counter any problem of our
machine please contact us, and we will arrange our engineer to
solve it.
