LED machine dual arm high precision with magnetic linear moter pick
and place machine
Advantages of F7S
High capacity | Apply to the 0.6m, 0.9m,1.2m rigid PCB and 0.5m,1m LED hard light
board and LED flexible strip. producing with 2~4 types of
materials with high capacity ,available for board with any
proportion of LED chip and resistors. |
High precision | Two mounting modules ,17 nozzles for each mounting part, part A or
B can be mounted separately or synchronously. |
Exclusive | Exclusive patent technology :group to take and group to mount. |
Parameter
Model | HT-F7S |
PCB Length Width | Max:1200*330mm Min:100*100mm |
PCB Clamping | Adjustable pressure pneumatic |
O.S. |
System | Windows7 |
Software | R&D independently |
Vision System |
Mounting Speed | 180000 CPH |
Components | LED 3014/ 3020/ 3528/ 5050 and capacitors, resistors, bridge
rectifiers, etc. |
Power | 380AC 50 HZ |
X,Y,Z Axis Drive way | High-end magnetic linear motor+ Servo motor |
Feeding System |
No. of Feeders Station | 68 PCS |
No. of head | 34 PCS |
Feeding way | Electric feeder with double motor |
SMT Production Line
1. Include automatic pick and place machine, solder paste stencil
printer, reflow ovens machine, conveyor, Excellent combination
2. From print solder paste to mounting components, the whole smt
line is equipment, you just need to decide the product, we give you
best suggestion for the production line
3. Flexible. We can provide automatic line or semiautomatic line.
It is flexible and decide by you.
4. Much save cost. Buy from one manufacturer save time, save money,
much easy for after sales service.
We can provide whole line solution if you want, we are very
professional on SMT field.
The following is the semi-automatic production line of F7S machine:
Application of F7S Mounter
F7S is the super high speed pick and place machine, it is suitable
for mounting board within 1.2 meters. Widely apply to rigid PCB and
flexible PCB. And suitable for mounting led chip, resistor, bridge,
RGB, etc.
So F7S very suitable for led module lighting, such as LED TUBE,
Strip, panel, street light, display, etc.
