R&D Independently YT202 LED and electric Making machine pick and place machine

Working principle

The placement machine can directly attach and solder surface-mounted components to the specified position without drilling insertion holes on the printing plate, which can be described as another product of industrial automation. The placement machine is mainly composed of a placement head and a static lens. First, the placement head grabs the nozzle and absorbs the components on the corresponding position of the PCB according to the package type, component number and other parameters of the imported placement components; secondly, the static The lens detects, identifies and aligns the pickup components according to the vision processing program; finally, the placement head mounts the components to the corresponding positions on the PCB board

Feature of Machine

Features

Vacuum Sensing Device

Each placement head with independent detection function,

which improves the stability of the equipment and the reliability of the product.

Ultra-high-speed Capability

Adopt High-end magnetic linear motor,servo system and multi function modular head,

the capacity increased by 25% compared with traditional machine,optimum placement

speed reach 80000 CPH.

High reliability

1.Brand new self-developed high-precision placement head.

2.Combine high accuracy Mark recognition camera with fixed flight vision camera,ensure placement accuracy.

3.The placement head adopt independent vacuum detection,improve placement performance.

4.Off-line programming, save time of changeover cycle.

5.Software Al intelligent learning function and automatic optimization function.

Main Parameter

Machine application

YT202S is high-end mounting machine, support for mounting 0201-40*40mm tape reel package and IC tray feeder.

The finished product like the household appliance driver board, tv display board, complicated BGA, Transistor, SOP, VR, CSP, QFP,TSOP mounting.

Certification

ETON obtains a number of intellectual property technologies, including 9 invention patents, 112 Practical patents, 12 software copyrights.ETON is rated as"Shenzhen high-tech enterprise" "Guangdong high-tech enterprise" "China high- tech enterprise""Shenzhen TOP Brand" "2015 LED Technology Innovation Award" "The 4th China LED First Innovation Award" "Industry Special Contribution Award" etc.

RFQ

Q: What is your actual speed of your products?

A: For the actual speed of the machine which is constrained by many factors,that relatedto the number of the components, the time to send PCB board and receive the board that will have influence on the speed when in production, and is decide for the actual products and needs.

Q: It’s hard to use the machine?
A: Machine is very intelligent and easy to operate, like the intelligent phone, also the software is made by our company, so we know how to make it more intelligent and operate friendly.

Q: Can I visit the production site of your machines in India?

A: I have to ask my clients. After all, this is our customer's factory. We can't make decisions for my clients.

I think that You wouldn't want your competitors to visit your manufacturing site. please understand.

Contact me:

David

Whatsapp/Wechat/Tel: +86 13827425982

Skype: +86 15573907263

E-mail: david@eton-mounter.com

QQ:3061340868

Shenzhen Eton Automation Equipment Co.,Ltd.

The 2nd. Floor, Building C2, Hengfeng Industrial Area, Zhoushi Road No.739, Hezhou community, Hangcheng Street,Baoan district,Shenzhen,Guangdong,China.

Shenzhen ETON Automation Equipment Co.,LTD. was establised in 2007,possess more than 300 staff at present and cover an area of more than 20000 square meters,is the largest leading manufacturer of high-speed pick and place machine and SMT machine for LED light production and Electronic field,which is also a high-tech enterprise and top brand well-known in China with good reputation.


  ETON invented the fastest automatic pick and place machine with speed 150000CPH,which is the fastest machine in the world,awarded many global first technology patent,also invented the global first machine for any length of 1M 5M 50M 100M 500M flexible LED strip,won large market in USA,KOREA,INDIA,GERMANY,EGYPT,TURKEY,VIETNAM,TUNISIA ETC.


  Since the establishment of the company, with the green and energy-saving development trends of global illumination and rapid development of LED industry and its requests for the manufacturing craft, ETON has seized the opportunity and risen quickly, they have independently researched、designed、manufactured a set of quicker、more stable、more optimal LED fully automatic, high speed, energy-saving chip mounter and multi-function chip mounter, which have been highly recognized in the industry for its absolute advantage in speed, stability and capacity, at the same time, it have solved the offset and fling material issues when producing 1.2 meters, 1.5 meters lamp plates and wireless long FPCB and shaped component at a high speed. ETON has passed ISO9001 quality management system certification and has obtained more than one hundred of patents and certificates, including for utility model, personal invention, software copyright and so on. We have established cooperative relationship with well-known enterprises at home and abroad, such asMLS,OPPLE,NVC,Navigation,PAK,ETI,FSL, Home Lighting,Yangguang Lighting, XSY, Sansi, India RK, India SURYA, Vietnam RANGDONG, Egypt FUTEK etc..

  Our products have been exported to more than 20 countries and regions, including Korea, India, Vietnam, Tunisia, Egypt, Turkey and so on. Meanwhile, the company has created customer service center, where records every customer and the sale of every set of machine permanently. Its existence can timely solve customer’s questions when using it, which truly provides the convenience and assurance for our customers.

  “High efficiency” “High quality” and “Stability” are the core technology of ETON,technology innovation and strict quality control,with excellent service,ETON has grown into the outstanding worldwide brand of SMT machine with good reputation.
