    SMD LED Chips Mounting Machine 90K CPH For LED Power Driver / LED Light

    Ask Lasest Price
    Brand Name : ETON
    Model Number : HT-E8D
    Certification : CE , ISO , CCC
    Price : USD 48000-72000 per set
    Payment Terms : T/T, L/C
    Supply Ability : 50 Unit per mouth
    Delivery Time : 15-30 days
    • Product Details
    • Company Profile

    SMD LED Chips Mounting Machine 90K CPH For LED Power Driver / LED Light

    smd led chips mounting machine for kinds of led power driver and led light with 90K CPH


    The main parameter


    ModelHT-E8D-1200
    Dimention3150*2250*1650
    Total weight2500kg
    PCB length widthMax:1200*300mm
    Min:100*100mm
    PCB thickness0.5-5mm
    systemwindows 7
    softwareR&D independently
    No.of camera4 sets
    vision for the flight identification, mark correction.
    Mounting speed90000CPH
    Componentsled chip, resistors, capacitors, IC, shaped components. etc.
    transmission directionBoth direction(option)
    transmission modeAuto online drive
    electrical controlIndependent research and development by ETON
    no.of.feeders system48pcs double modules
    no.of .head24pcs double modules
    feeding wayElectric feeder with double motor

    Features


    High Capacity:24 Heads, dual system dual module;Producing two different products at same timeOptimum speed 90000 CPH

    High Stability: with high end magnetic linear motor and servomotor, Production Stability.

    High Precision: 4 sets ofimported camera, with flight visioncamera, mark correction

    Wide Application: widely apply to all kinds of led lights andelectric board

    Automatic feeding: if there is leakage or throwing, it canautomatically feed to save labor.

    Software: Software R&D, Updated free for life, English &Chinese language version


    Production line

    The production line of HT-E8D-1200 is semi-automatic production line, including semi-automatic stencil printer, conveyor, pick and place machine, reflow oven.


    Application products

    HT-E8D-1200 is a multi-functional and double module smt machine, which is apply to all kinds of led lights and electric board. Such as led bulbs, DOB bulbs, led strip light, led down light, led tube light, led spot light, led street light, led flood light, corn light, electric board, led power driver, home appliance etc.


    FAQ

    Q1: What is your machine actual speed?

    A1: The actual speed is influenced by many factors, such as the number of the components, the kind of products, the time of send board, etc.

    Q2: do you only provide smt pick and place machine?

    A2: no, we can provide whole line solution if you want, loader&unloader, conveyor, reflow oven etc.

    Q3: how about the machines quality?

    A3: We have our own industrial park. There are production centre and R&D centre and quality inspection centre to guarantee the machine quality.
