Used to achieve dot, line, round or arc shape SMT glue dispenser
machine
Description
The glue dispenser is also called the glue spreader, which
specifically controls the fluid. The automatic machine that drips
and coats the fluid on the surface of the product or the inside of
the product can realize three-dimensional and four-dimensional path
dispensing, precise positioning, precise control of glue, no
drawing, no leakage, no glue. The glue dispenser is mainly used to
accurately point, inject, apply and drop glue, paint and other
liquids in the product process to the precise position of each
product. It can be used to achieve dot, line, round or arc shape.
Machine main features
- English interface option, easy to operate;
- CCD positioning system, visual positioning compensation
automatically, correct the deviation of PCB;
- Large size track, suitable for different size of PCB;
- Contactless high speed injection dispensing head, dispensing glue
continuously with high efficiency;
- Intelligent dispensing head ensure good performance, high
efficiency and lower wasting;
- Dispensing head constant temperature function, ensure the glue in
liquid;
- Control the dispensing value in milliseconds, ensure the conformity
of glue volume;
- Online visual programming, more convenient;
- Automatic program standby, start up production rapidly, Intelligent
manufacturing;
- Apply to various kind(round, linear, lattice, etc.) of products;
- High performance linear motor drive for X, Y axies, ensure high
accuracy in high speed;
- Universal signal connecting, connect equipment online easily;
- large capacity SSD industrial control system,high speed access
ensures system response speed.
Machine main parameter
| Model | HT-D12-1200 |
| Dimension | Length: 1800 mm Width: 1050 mm Height: 1550 mm |
| Total weight | 800 KG |
| Max PCB size | 1200*500 mm |
| Dispensing accuracy | 0.1 mm |
| Dispensing speed | 90000 CPH |
| Dispensing height | <15 mm |
| Max running speed | 1200 mm/sec |
Application
Our advantage
We can provide SMT line solution for you!
Pick and place machine/reflow oven/stencil printer/pcb
conveyor/SPI/AOI.etc
1.Light Factory for :led bulbs,DOB,lens,panel
light,downlight,streetlight,tube,0.5m,1m strip light,etc.
2.Provide Overseas engineers for Free installation and free
training.
3.TOP brand of China SMT machine manufacturer,500 employees for
ETON
Service
Pre-sale service
Provide suitable production plan
Advise on plant electrical equipment and layout
Sale service
Report machine status in time
Follow up and send test machine video
After-sales service
Software lifetime upgrade
24 hours to deal with problems online
Engineers can arrive on site to teach operation and debug the
machine
Regular visit (one year warranty period, spare parts repair free;
Once or twice a year after warranty)
Related machine
We can provide a whole SMT production line,led light production line:
1.Pick and place machine
2. Loader machine
3. Conveyor machine
4. Stencil printer machine
5. Reflow oven machine
6. Unloader machine
7. Solder paste mixer
8. Roll to roll led strip light assembly machine
FAQ
Q. Can I use CIF price?
A. CIF price need add the freight and insurance fee, while for the
part of EXW which is cheaper and convenient factor as a suitable
price for both sides.
Q. What is your machines quality?
A. As an experienced manufacturer in SMT machine, we obtained a
number of intellectual property technologies, including 9 invention
patents, 112 practical patents, 12 software copyrights, with our
won R&D department for production and inspection. And awarded
as “China high-tech enterprise”, “Shenzhen TOP brand” we ensure our
high quality of our machine as an excellent manufacturer in China.
Q. Is the machine easy to operate?
A. Yes, our machine is very intelligent and easy to operate, like
the intelligent phone, also the software is made by our company, so
we know how to make it more intelligent and operate friendly.
