Programmable suspension printing head FPCB Max 260mm Automatic stencil printer
Description
● Programmable suspension printing head;
● Two sets of stepping motor drive, the pressure of front and rear
scraper can be adjusted separately to ensure the inconsistency of
front and rear printing caused by fatigue deformation of scraper
material;
● Effectively control the stroke, improve the printing efficiency,
and prevent the leakage of solder paste;
● Standard stainless steel scraper, unique design, improve the
service life of the blade;
● Downward vision alignment system;
● CNC guide rail adjustment;
● Industrial controlled computer,Windows XP interface operating
system;
● Built-in software diagnostic system;
● SMEMA interface.
Technical parameter
| Screen Frames | Min Size | 850mm |
| Max Size | 550mm |
| Thickness | 25~45mm |
| FPCB Min Size | 50mm |
| FPCB Max Size | 260mm |
| FPCB Thickness | 0.5~5mm |
| FPCB Warpage | Max. FPCB diagonal 1％ |
| Transport Height | 900±40mm |
| Transport Direction | Left-Right |
| Transport Speed | Max 1000mm/S Programmable (Adjustable) |
| Board Location | Support System | Platform jacking tension |
| Clamping System | Edge clamp fixed |
| Print head | Two independent motorized print heads |
| Squeegee Speed | 6~300mm/sec |
| Squeegee Pressure | 0~10Kg/cm2 |
| Squeegee Angle | 55°(Standard) |
| Squeegee Type | Stainless steel(Standard), plastic |
| Stencil Separation Speed | 0.1~20mm/sec Programmable |
| Cleaning System | Manual cleaning |
| Table Adjustment ranges | X:±5mm;Y:±5mm;θ:±2° |
| Machine |
| Repeat Position Accuracy | ±0.01mm |
| Printing Accuracy | ±0.025mm |
| Cycle Time | ≤9s (Exclude Printing & Cleaning) |
| Air Required | 4.5~6Kg/cm2 |
| Power Input | AC:220±10%,50/60HZ 1Φ 1.5KW |
| Control Method | PC Control |
| Machine Dimensions | 1754(L)X1249(W)X1600(H)mm |
| Machine Weight | Approx:600Kg |
| FPCB transport over plate height | 20mm |
Certificates
As an experienced manufacturer in SMT machine, we obtained a number
of intellectual property technologies, including 9 invention
patents, 112 practical patents, 12 software copyrights, with our
won R&D department for production and inspection. And also
earned the oversea certificates as CE, CCC, SIRA,etc.
Service
Maintenance period 1 year
One year warranty during warranty any parts that need to be
repaired and replaced will be free.
Software and hardware lifetime maintenance
Free upgrade software, the software is Reach and developed by ETON,
so we support whole lifetime free upgrade updates.
Visit customers regularly and gather information
Visit clients regularly. We attend the different exhibitions in
different cities every year, at the same time, we will visit local
clients and support our service and collect feedback on customer
suggestions in time.
Provide the latest information about technology and equipment
We give professional technology suggestions to our clients. And
share the updated news with our clients
On-site service
We have some official site in India as Mumbai and New Delhi, also
have site in Egypt, Turkey that can provide service timely with our
engineers.
According to your needs, dedicated senior engineer will come to
your factory for free install and training you how to operate the
machine.
Shipping and Delivery
Shipping Way:
※ By air, for sample and small package
※ By sea, for large package and quantity;
※ Other ways as customer requested.
Delivery Time:
※ Within 30 Days.
Related machine
We can provide a whole SMT production line,led light production line:
1.Pick and place machine
2. Loader machine
3. Conveyor machine
4. Stencil printer machine
5. Reflow oven machine
6. Unloader machine
7. Solder paste mixer
8. Roll to roll led strip light assembly machine
FAQ
Q.How can I make inspection when something wrong with the machine?
A. Well, the inspection is taken by our professional engineer to
check and modulate the machine, if you counter any problem of our
machine please contact us, and we will arrange our engineer to
solve it.
Q. How was your services?
A. We ensure our clients to enjoy an optimal experience of the
service of communication and relevant needs of the machine for
installation, maintenance and free up- grade.
Q. How long is the machine maintenance period, whether it is free?
A. The maintenance period of our machine is 1 year and its free for
our clients, after the maintenance period we will arrange our
engineers to check and test the machine one or two times a year
freely.
