F8: 5 sets of imported camera for RGB For Chip Mounter Machine
Technical Data
| PCB | PCB Length Width | Max:345*600mm Min: 110*80 mm |
| PCB Thickness | 0.5~5mm |
| PCB Clamping | Adjust and fix PCB automatically by software |
| Mounting Mode | Group to pick and group to mount |
| O.S. | system | Windows7 |
| software | R&D independently |
| Display | LED Monitor |
| Input Device | Keyboard, Mouse |
| Feeding system | No. of feeders | 32 PCS |
| No. of nozzles | 32 PCS |
| Feeder type | Electronic feeder |
| Vision System | No. of Camera | 5 sets of imported camera |
| Vision for the flight identification + MARK correction |
| Mounting Precision | ±0.02mm chip |
| Mounting Height | <15mm |
| Mounting Speed | 150000CPH(optimum) |
| Components | LED 2121/2727/3528/3535/5050 and resistor, capacitors, bridge
rectifiers. |
| Components Space | 0.2mm |
| Power | 220AC 50HZ |
| Power Consumption | 5 kw |
| Operating Environment | 23℃±3 |
| Conveyor Transmission | Max length:600 mm |
| Transmission Speed | >500mm/sec |
| Transmission Direction | Single(left→right or right→left) |
| Transmission Mode | Online drive |
| Air pressure | >5.0kg/cm2 |
| Electrical control | Independent research and development by ETON |
| Motion control card module | Independent research and development by ETON |
| X,Y Axies Driving | Servo motor control for X,Y,Z axies |
specialty
Adjust and fix PCB automatically by software, No need support plate for mounting
LED display, two model, 32 nozzles totally, part A and part B can
work separately or synchronously. Correction automatically, high
precision, available for RGB.
Global first technology patent: counterfeiting not allowed.
IPC 9850 Capacity:150000-170000 CPH
Patent number: ZL 2011 2 0237740.9 ZL 20 11 2 0334606.0
ZL 2012 2 0178869.1 ZL 2012 2 0415505.0
ZL 2012 2 0415044.7 ZL 2012 2 0415356.8
ZL 2012 2 0415061.0
